Document type Technical Data Sheet

Name VENETIAN FAÇADE

Description Natural, lime-based material for decorative finishes on interior and exterior wall

surfaces. Venetian Facade is a revolutionary Venetian Plaster for high humidity

environments, with a composition that boasts hydraulic properties and specialised

additives to provide exceptional resistance against mould and moisture.

Composition Hydraulic lime and selected marble powders

Grain size 700 microns

Appearance Powder

Colour White, it can be tinted in any colour with lime-compatible colourants

Packaging 16 kg net polyethylene containers

Application By hand, with a steel trowel

Type of Surface Interior and exterior walls

New Wall Surface

Plaster: no priming necessary

Gypsum / Plasterboard / Medium Density: one coat of QUARTZ PRIMER

Old Wall Surface

Plaster: one coat of QUARTZ PRIMER

Fast drying / Limewash: brush down and apply one coat of QUARTZ PRIMER

Polished Lime: Abrade, brush down and apply one coat of QUARTZ PRIMER

Washable Paint: one coat of QUARTZ PRIMER

Dilution Put the 16 kg of powder into a tub with 6.4 L of water and mix (For every 1 kg of

powder, add 400 ml of water to achieve the correct dilution ratio). Wear a protective

mask and glasses when mixing.

Consumption 1.7 – 2.2 kg / sqm of powder after 2 or 3 coats

Drying 5 hours at 20°C / 68°F to the touch

72 hours at 20°C / 68°F below the surface

150 days stable

Application temperatures min 5 max 30°C – R.U. < 85% ca

Coat Thickness 1.2 – 1.7 mm for a total of 2-3 coats

VOC Classification EU Directive 2004/42/CE: EU limit value for this product (cat A/l – water-based

decorative effect coating): 200 g/l (2010). This product contains less than 1 g/l of VOC.

Specific Weight 1.4 ± 0.2 (g/L)

pH after 30 days 12.4 ± 0.50

Vapour Permeability SD ~ 0,04 m (DIN 52 615)

Flammability European Class of Reaction to Fire A1: non-combustible – no contribution to fire

Mould Resistance ASTM D 3274 – “Standard Test Method to evaluate the degree of surface

disfigurement of paint by microbial, fungal and algae growth.

Result: Front Panel 10/10/10 Back Panel 10/10/10 = no growth

April 23 TDS VENETIAN FAÇADE 2 of 4

Scrub Test Resistance ASTM D 2486-06 method A = was used: scrubbing fine sand + metallic brush for

10,000 cycles

Impact Test UNI EN ISO 6272-2-2006. 1 kg doming punch was dropped from different heights and

only at the height of 8 cm., it left a 5.5 mm. dent in the surface and a tiny crack

appeared around its circumference.

Pencil Hardness ASTM D3363- Pencil hardness 5H

Shore Hardness Norm ASTM 2240 average

Adhesion Norm UNI EN 13892-8 2004 average value = 2,0

Pot life 4 hours on average

Shelf life 24 months when stored according to the recommended guidelines

Storage In original sealed packaging between 5° - 35°C in a dry, dark environment

Safety Norms Irritating. / Risk of serious damage to eyes. / Irritating to the skin. / Keep out of children.

/ Avoid contact with eyes. / In case of contact with eyes, clean immediately with water

without rubbing them, and consult a doctor. / Wear suitable gloves and eyes / face

protection. / In case of ingestion of the products, consult immediately a doctor showing

him the can or the label of the product. Danger labelling under directives 67/548/EEC

and 1999/45/EC nd following amendments and adjustments. The product must be

transported, used and stored according to current standards of hygiene and safety.

Disposal Product must be disposed of according to norms and regulations in force. Containers

must be sent for recycling. Follow directions on the packaging

Application Instructions WARNINGS

We recommend using materials from the same production batch for the same project.

If you must use different batches, we suggest mixing their material together to avoid

any slight variations in shading.

To ensure proper usage, dilution, and application of the products mentioned in these

pages, please consult the corresponding technical data sheets.

When preparing the surface and applying the materials, we advise using appropriate

tools and personal protective equipment (PPE).

During application and for the following 72 hours, protect the surfaces from sudden

temperature change, direct sun light and water. Don’t apply in temperatures below 8°C

or above 35°. During application make sure that the work area isn’t too damp or warm

to avoid problems with application times.

Remember to have a strong light parallel to the wall and situated on only one of the

two sides of the wall you are working on (usually on the same side as other sources of

light such as windows). In this way the shadow of the trowel allows you to see the

actual state of the finish. Every so often, during the second and third coat, the light

should be moved so that the wall doesn’t dry out too much in one spot from the heat of

the lamp.

APPLICATION

April 23 TDS VENETIAN FAÇADE 3 of 4

Apply the primer with a roller or brush. A primer containing quartz sand is

recommended. Lime-based and sand plasters which are clean don’t need to be

primed.

1. Using approximately 600-750 gm/sqm apply it directly to the substrate plaster, taking

care to apply it evenly so as to smooth out any imperfections on the surface. On ideal

substrates, such as new plasters of lime/cement and fine sand, the first coat can be

skipped, starting application from the second coat.

2. If you apply the second coat as evenly as possible with a metallic trowel you will get

little or no dark and light effect, but if you apply it unevenly, you will get more of a dark

and light effect, specially with dark colours. To do this coat make sure the blade-edge

of the trowel is always clean and free of imperfections. The edge can be cleaned with

P360 sandpaper. Usually the second coat is applied over the entire surface before

applying the third coat. But on large surfaces in hot, dry conditions it might be

necessary to have a second person begin to apply the third coat while the first person

completes the second coat.

3. Using approximately 100-120 gm/sqm, apply the third coat before the second coat is

completely dry, that is ‘wet-into-wet’, so that the grains of marble penetrate into the

previously applied coat. With this hand, proceed with the final smoothing and polishing.

For a greater polish, go over the surface repeatedly with the trowel.

EXTERIORS

For exterior applications there are some rules to respect and some precautions to take.

We remind you that carbonation, i.e. the process that takes place through the

absorption of atmospheric CO2, is completed in a few hours on the surface but takes

several days to take place in depth. It is therefore important that the application takes

place in the certainty of the absence of heavy rains in the three following days. It is also

not recommended to apply it on walls that do not have at least a small roof overhang.

Penetrating rain could ruin the finish even after weeks as deep carbonation is

completed after more than a month. Avoid windy days, especially at high temperatures,

as well as the risk of frost in the 48 hours following application. In external applications

in hot climate conditions, it is also recommended to protect the wall from the sun with

shade cloths applied to the scaffolding. Lime-based products must dry slowly to better

fulfil their characteristics.

Finish Protection INTERIOR: BEESWAX / MINERAL WAX / MARSEILLE SOAP / HYDROCALCE

EXTERIOR: MARSEILLE SOAP / HYDROCALCE

WET AREAS: PU1C

A protective treatment is optional in most circumstances. It is however necessary in

bathroom walls, kitchen and splashback walls, and a must inside shower/sauna walls.

On exteriors, protective treatments are obligatory only in highly polluted cities.

Interiors

After a minimum of 48 hours, at least one coat of the following can be applied:

April 23 TDS VENETIAN FAÇADE 4 of 4

A) MARSEILLE SOAP protective coating with a steel trowel. After 48 hours, go over

the surface with a cloth to remove the coat of surface powder produced by unabsorbed

soap.

B) BEESWAX WAX applied with a sponge. After a little while, before it dries, rub

vigorously with a woollen or soft cloth to obtain an even polish.

C) MINERAL WAX applied with a sponge. After a little while, before it dries, rub

vigorously with a woollen or soft cloth to obtain an even polish.

Exteriors

This finish, as all lime-based plasters, absorbs water during rainy weather, which

results in a temporary "wet effect" on the surface. However, this plaster releases the

absorbed water within a few hours, allowing the surface to dry without any damage nor

alteration to the finish. While a final treatment is therefore optional, it is highly

recommended in areas with high pollution levels or if you wish to avoid the temporary

wet effect that can occur after rainfall. To protect the finish, after at least 72 hours at a

minimum of 20°C, proceed with a colourless, penetrating HYDROCALCE, developed

to protect exterior plaster coverings.

Maintenance No special work is required in maintenance, just remove the dust periodically and re-

wax it after 5 or 6 years if applies. Protect the coating from any contact with liquid

either rain or continuous water flowing down the wall. If any liquid such as coffee is

spilled on the surface, clean immediately.

Tools SI TROWEL / BIANKO, SCRAPERS, CORNER TROWEL, NON-WOVEN FABRIC

Clean with water immediately after use

Decorative complements

(optional)

MICA / TERRACOTTA / SALT & PEPPER / MILLED MARBLE / EBANO POWDER

METALLIC BEESWAX / PERLA WAX

We have drawn up the material presented above to the best of our technical and experiential knowledge. Nevertheless,

our suggestions and recommendations are not guaranteed. All responsibility for the obtained results lies solely with the

method and conditions adopted for the application of the product. Such indications constitute valid support for verifying

the product's suitability for the specific case. We reserve the right to make modifications to the present information
