Technical Data Sheet

Document Type: Technical Data Sheet

Name: ERA STONE

Description:Natural, lime-based material for decorative finishes on interior and exterior wall surfaces. Naturally anti-mould and breathable. The final finish is textured, with pleasing chiaroscuro effects. It resembles the Roman stone, from which it takes its name.

Composition:Aged, slaked lime and selected marble powders

Available Versions:ERA STONE, ERA STONE WHITE

Grain Size:1 mm

Appearance:Paste

Colour:The standard ERA STONE is a pale beige, while the WHITE version is white and can be coloured to any hue

Packaging:24 kg net polyethylene containers

Application:By hand, with a steel trowel

Type of Surface:Interior and exterior walls

New Wall Surface:

  • Plaster: no priming necessary
  • Gypsum / Plasterboard / Medium Density: one coat of QUARTZ PRIMER

Old Wall Surface:

  • Plaster: one coat of QUARTZ PRIMER
  • Fast drying / Limewash: brush down and apply one coat of QUARTZ PRIMER
  • Polished Lime: Abrade, brush down and apply one coat of QUARTZ PRIMER
  • Washable Paint: one coat of QUARTZ PRIMER

Dilution:Ready to use

Consumption:3.5 kg after two coats

Drying:

  • 4 hours at 20°C / 68°F to the touch
  • 48 hours at 20°C / 68°F below the surface
  • 180 days stable

Application Temperatures:min 5 max 30°C – R.U. < 85% ca

Coat Thickness:1.9 – 2 mm for a total of 2 coats

VOC Classification:EU Directive 2004/42/CE: EU limit value for this product (cat A/l – water-based decorative effect coating): 200 g/l (2010). This product contains less than 1 g/l of VOC.

Specific Weight:1.4 ± 0.2 (kg/l)

pH After 30 Days:12.5 ± 0.50

Vapour Permeability:SD ~ 0.04 m (DIN 52 615)

Flammability:European Class of Reaction to Fire A1: non-combustible – no contribution to fire

Mould Resistance:ASTM D 3274 – “Standard Test Method to evaluate the degree of surface disfigurement of paint by microbial, fungal and algae growth. Result: Front Panel 10/10/10 Back Panel 10/10/10 = no growth

Scrub Test Resistance:ASTM D 2486-06 method A = was used: scrubbing fine sand + metallic brush for 10,000 cycles

Impact Test:UNI EN ISO 6272-2-2006. 1 kg doming punch was dropped from different heights and only at the height of 8 cm., it left a 5.5 mm. dent in the surface and a tiny crack appeared around its circumference.

Pencil Hardness:ASTM D3363- Pencil hardness 5H

Shore Hardness Norm:ASTM 2240 average

Adhesion Norm:UNI EN 13892-8 2004 average value = 2.0

Shelf Life:36 months when stored according to the recommended guidelines

Storage:In original sealed packaging between 5° - 35°C in a dry, dark environment

Safety Norms:Irritating. / Risk of serious damage to eyes. / Irritating to the skin. / Keep out of children. / Avoid contact with eyes. / In case of contact with eyes, clean immediately with water without rubbing them, and consult a doctor. / Wear suitable gloves and eyes / face protection. / In case of ingestion of the products, consult immediately a doctor showing him the can or the label of the product. Danger labelling under directives 67/548/EEC and 1999/45/EC and following amendments and adjustments. The product must be transported, used, and stored according to current standards of hygiene and safety.

Disposal:Product must be disposed of according to norms and regulations in force. Containers must be sent for recycling. Follow directions on the packaging.

Application Instructions:

WARNINGS:Water on the surface of the material in the bucket is normal and should be removed before use or addition of colourants. All lime-based products lose their viscosity when mixed and need a period of 6/12 hours after mixing to regain their density. This product is dense, and ready for use; thus it may be necessary to use an appropriate drill attachment to stir for a few minutes to reduce viscosity. Choose the colour and add the toner additive to the container and continue mixing until a homogeneous shade is obtained. Let the product rest for about 5 hours before you begin to use it. We recommend using materials from the same production batch for the same project. If you must use different batches, we suggest mixing their material together to avoid any slight variations in shading. To ensure proper usage, dilution, and application of the products mentioned in these pages, please consult the corresponding technical data sheets. When preparing the surface and applying the materials, we advise using appropriate tools and personal protective equipment (PPE). During application and for the following 72 hours, protect the surfaces from sudden temperature change, direct sunlight, and water. Don’t apply in temperatures below 8°C or above 35°C. During application make sure that the work area isn’t too damp or warm to avoid problems with application times. Remember to have a strong light parallel to the wall and situated on only one of the two sides of the wall you are working on (usually on the same side as other sources of light such as windows). In this way the shadow of the trowel allows you to see the actual state of the finish. Every so often, during the second and third coat, the light should be moved so that the wall doesn’t dry out too much in one spot from the heat of the lamp.

APPLICATION:

Suitable Surfaces for ERA STONE:It can be applied on any surface including drywall or wood panelling as long as a primer is applied first. Suitable for interior and exterior surfaces.

Preparation of the Work Environment:Protect the floor, baseboards, and windows. Remember that alkaline products can leave marks on aluminium and some kinds of wood.

Applying the Primer:Apply the primer with a roller or brush. A primer containing quartz sand is recommended. Lime-based and sand plasters which are clean don’t need to be primed.

Colouring ERA STONE:After opening the container, pour out all the water on the surface, and mix well with an electric mixer for 30 seconds and then pour in all the necessary colorant. Mix well until the colour is homogeneous. During application, remember to always have strong illumination angled at the surface of the wall you are working on. If there is a window, put the light source on the same side as the window to have all the light coming from one side. If the lamp produces a lot of heat, it is best to move the lamp occasionally so that during the second and third coats, one part does not dry too quickly. It is best not to apply in temperatures below 5°C or with elevated humidity.

  1. Apply one thin coat uniformly in the colour desired over the entire surface with a metal trowel. Avoid leaving too many ridges. After the first coat, it’s best to replace all the masking around doors, windows, and ceilings.
  2. Once the first coat is completely dry, you can apply the second coat with a metal trowel. The edge of the blade should be smooth and free of imperfections. Normally the second coat is applied over the entire surface before applying the final coat, but if the wall is big or it is very warm out, it is recommended that the work be done in a team with one completing the second coat, while the other begins applying the final coat since the third coat need to be applied on a damp 2nd coat.
  3. When the material has been applied well and smoothed almost like a Marmoretto, you can begin to “scrape” the surface using a spatula or the blade of the trowel set at a 90-degree angle in respect to the wall. Move the blade against the plaster with horizontal (or vertical) movements.
  4. Go over the entire scraped surface to smooth it out again (as usual, moving parallel, that is with the “grain”). After this, check to see if any areas need to be re-scraped at any points.
  5. If you want the smooth parts to be polished, you can polish them with a metal trowel followed by a plastic one.

ERA STONE Romano – an Alternative Application:A more popular application is done using the “plastic grass brush” to draw the ERA STONE effect. Apply and smooth the second coat and create a pitted drawing pressing the surface. Smooth the surface again and if necessary, draw the effect once again with a plastic brush.
